The pump is a horizontal twin stage cast iron centrifugal pump supplied wired and ready to install.

Used especially for water transfer.

The pump is characterised by:

• Corrosion resistant cast iron pump body, bracket cover and support with cataphoresis1 treatment, and 304 stainless steel impeller and shaft.

• Mechanical shaft seal - Carbon/Ceramic

• 240V single phase TEFC motor with in-built auto reset thermal overload.

• Motor support foot.

Applications:

Suitable for industrial wash down, water transfer and tank filling.

Suitable for fire fighting, HVAC, circulation and pressure boosting.

Cataphoresis is an electrochemical coating process for metallic surfaces widely used in the industry due to its penetration and long life, either as a priming coat or finished paint for corrosion resistance.

Package Information:

• 21 kg

• L 445mm x W 255mm x H 300mm

Centrifugal Pump
Cataphoresis coating, stainless steel impeller.
1.5kW, 2.0hp, 240V, max hd 57m, max flow 160L/m.
Ports 1-1/2” BSPF In, 1” BSPF Out.

Warranty

2 Year BIANCO Pumpz Warranty
